LPI14 Self-Operated Differential Pressure Control Valve
LPI14 self-operated differential pressure control valve is composed of the control valve, actuator and a spring used for pressure setting.
It is suitable for controlling differential pressure in the pipes of non-corrosive liquids,gases and steams.when the differential pressure rises, the control valve is closed/open.
The main features are as follows:
- It has the pressure balancing function with high sensitivity.
- Low noise, reliable performance,free of maintenance.
- The standard modular design is a opted.
- Various combined controls can be carried out through the assemblies.
| Size | DN15~250 |
| Pressure Rating | PN16, 25, 40 |
| Pressure Balance Devices | Bellows, Cage |
| Characteristics | Quick Opening |
| Allowable Differential Pressure | 1.0~2.0Mpa |
| Allowable Overload | With 20% of the setting value |
| Leakage | Class IV |
