LPI13 Self-Operated Flow Control Valve

LPI13 self-operated flow control valve is composed of the control valve provided with flow setting and actuator.

It is suitable for controlling flow in the pipes of non-corrosive liquids.

The main features are as follows:

• It has the pressure balancing function with high sensitivity.
• Low noise, reliable performance,free of maintenance.
• The standard modular design is a opted.
• The flow is adjusted according to the standard figure by the throttle valve, which is convenient and fast.
• Various combined controls can be carried out through the assemblies.

Size	DN15~250
Pressure Rating	PN16, 25, 40
Pressure Balance Devices	Bellows, Cage
Characteristics	Quick Opening
Allowable Differential Pressure	0.02~2.0Mpa
Allowable Overload	With 20% of the setting value
Leakage	Class IV
