API 6D Plug Valve, Soft Sleeve API Plug Valve, DBB Plug Valve
- INVERTED PRESSURE BALANCE LUBRICATED PLUG VALVE
- SLEEVE TYPE SOFT SEALING PLUG VALVE
- DOUBLE BLOCK AND BLEED PLUG VALVE
Design Feature
- API 6D standard
- Long service life plug and sealing
- Double sealing
- Two way oil groove, easy maintennace
- Pressure balance desigh
- Full bore, redduced bore and venturi bore available
- Anti-static design
- Fire-safe design
- ISO5211 standard mounting pad
Cast Steel material is available, customizied size maximum to 30" and CL2500.
Parameter
| Actuator | Electric, Pneumatic, Electro-hydralic, Manual |
| Control | On-off, Modulating, Inteligent |
| DN | 2"~14" |
| Pressure | ANSI CL150~CL2500 |
| Temperature | NBR: <120°C RTFE: <150°C VITON: <240°C |
| Connection | Flange, Welded |
| Structure | Full bore, redduced bore and venturi bore |
| Body Material | SS316L, SS316, SS304, SS304L, WCB, CE3MN, etc |
| Ball Material | SS316L, SS316, SS304L, CE3MN, etc |
| Sealing Material | Nylon, Devlon, PTFE, PEEK |
| Medium | Gas, Water and Oil, etc |
| Option | Limit Switch, Positioner, Solenoid Valve, Pressure-relief Valve |
API 6D Plug Valve
